中高压脉冲发生器

Medium Voltage Pulse Generators

Rise Time > 1 ns


Key Features

Connectivity - A variety of connectivity options is made available (based on model variation). Standard conectivity includes: IEEE-488.2 GPIB and RS-232 computer control feature for models with -B.

Software - Labview drivers are available for selected models.

Ethernet Ports and Remote Operation - Selected models have Options to add an ethernet port allowing the devices to be remotely accessed and controlled with secure protocols.

Front Panel Interface - The interface contains memory to store up to four complete instrument setups. The operator can use the front panel or the computer interface to store a complete "snapshot" of all key instrument settings, and recall this setup at a later time. This simplifies the setup of frequently performed experiments.



Please check the table below for individual specifications tied to individual products.


ProductVout (max)Rise time (20%-80%)Pulse width (FWHM)PRFGPIBBrochures
AVR-9A-B pulse generator12 V10 ns0.2-2000us50 kHzYESAVR-9 Series Brochure
AVR-9B-B pulse generator20 V15 ns0.2-2000us50 kHzYES
AVR-9C-B pulse generator12 V50 ns0.2-200us5 kHzYES
AVR-9D-B pulse generator20 V80 ns0.2-200us5 kHzYES
AV-1015-B pulse generator50 V10 ns20ns-10ms10 MHzYESAV-1010, AV-1011, AV-1015 Series Brochure
AV-1011B1-B pulse generator100 V2 ns100ns-1ms100 kHzYES
AV-1010-B pulse generator100 V10 ns20ns-10ms1 MHzYES
AVR-1A-B pulse generator50 V10 ns100ns-100us100 kHzYESAVR-1, -2, -3 & -4 Series Brochure
AVR-2A-B pulse generator100 V10 ns100ns-100us100 kHzYES
AVR-2B-B pulse generator100 V10 ns100ns-100us100 kHzYES
AVR-3-B pulse generator200 V10 ns0.1us-100us10 kHzYES
AVR-3HE-B pulse generator200 V10 ns50ns-100us100 kHzYES
AVR-3HF-B pulse generator250 V10 ns0.1-100us100 kHzYES
AVR-3HG-B pulse generator300 V12.5 ns50ns-100us20 kHzYES
AVR-4-B pulse generator400 V15 ns0.1us-100us10 kHzYES
AVR-5B-B pulse generator500 V20 ns0.1us-100us10 kHzYESAVR-5, AVR-7, and AVR-8 Series Brochure
AVR-7B-B pulse generator700 V20 ns0.1us-100us10 kHzYES
AVR-8A-B pulse generator1000 V50 ns0.2us-200us1 kHzYES
AVR-A-1-PW-B pulse generator200 V10 ns50-500 ns100 kHzYESAVR-A & AVR-S Series Brochure
AVR-A-1-S2-C pulse generator200 V2 ns10-200ns10 kHz
AVR-AHF-1-B pulse generator250 V10 ns50-500ns100 kHzYES
AVR-S3-B pulse generator200 V2 ns0.1us-5us10 kHzYES
AVR-E2A-B pulse generator50 V1.5 ns10-500 ns200 kHzYESAVR-E Series Brochure
AVR-E3A-B pulse generator100 V1.5 ns10-500 ns200 kHzYES
AVR-E6-B pulse generator100 V2 ns8-30ns2 MHzYES
AVR-GHV1-B pulse generator500 V40 ns0.2us-0.5sec1 kHzYESAVR-GHV Series Brochure
AVR-GHV2-B pulse generator500 V40 ns0.2us-0.5sec1 kHzYES
AVR-GHV4-B pulse generator400 V30 ns1us-0.5sec100 kHzYES
AVR-GHV5-B pulse generator800 V100 ns1us-0.5sec50 kHzYES
AVR-GHV6-B pulse generator500 V100 ns0.2us-0.5sec10 kHzYES
AVR-G1-B pulse generator250 V20 ns0.1us-1ms10 kHzYES




AVR-G5-B pulse generator440 V20 ns200ns-0.5s100 kHzYES
AVRF-4A-B pulse generator400 V5 ns0.15us-10us10 kHzYES




AVRF-7B-B pulse generator750 V8 ns90ns-10us5 kHzYES
AVRH-2-B pulse generator2000 V80 ns0.2us-2.5us1 kHzYES




AVRH-3-B pulse generator3000 V100 ns0.2us-2.5us1 kHzYES
AVRK-1-B pulse generator300 V3 ns (2 ns opt)5-100 ns1 kHzYES
AVRK-2-B pulse generator400 V3 ns (2 ns opt)7-65ns1 kHzYES
AVRK-3-B pulse generator550 V4 ns (2 ns opt)6-35ns1 kHzYES
AVRK-4-B pulse generator750 V4 ns (2 ns opt)6-20ns1 kHzYES
AVRQ-4-B pulse generator1500 V25-250 ns1 us10 HzYES




AVRZ-5W-B pulse generator500 V6.5 ns15ns-10us5 kHzYES




AVMR-3-B pulse generator50 V2.5 ns10-100 ns3 MHzYES




AVIR-2-B pulse generator200 V1.5 ns3-10 ns20 kHzYES
AVIR-3-B pulse generator200 V2 ns10-200 ns20 kHzYES
AVIR-4-B pulse generator200 V2 ns4-200 ns20 kHzYES
AVIR-4D-B pulse generator200 V2 ns4-1000 ns20 kHzYES
AVOZ-D1-B pulse generator500 V70 ns0.2us-10us5 kHzYES
AVOZ-D2-B pulse generator700 V100 ns0.2us-10us2.5 kHzYES
AVOZ-D3-B pulse generator200 V50 ns0.2us-10us5 kHzYES
AVOZ-D4-B pulse generator200 V50 ns0.2us-10us5 kHzYES
AVOZ-D6-B pulse generator1000 V200 ns1us-10us500 HzYES
AVOZ-D7-B pulse generator1000 V120 ns0.2us-10us1 kHzYES
AVOZ-E1-B pulse generator50 V50 ns0.5us-10us10 kHzYES
AVOZ-E2-B pulse generator100 V80 ns0.5us-10us10 kHzYES
AVOZ-E3-B pulse generator250 V150 ns0.5us-10us1 kHzYES
AVOZ-E4-B pulse generator250 V100 ns0.5us-10us3 kHzYES
AVOZ-E5-B pulse generator500 V200 ns0.5us-10us500 HzYES
AVL-AV-1-W-B pulse generator100 V2 ns5-400 ns50 kHzYES
AVL-2A-W-B pulse generator160 V2 ns3-400 ns20 kHzYES
AVL-2D-B pulse generator240 V1.5 ns10-100 ns20 kHzYES
AVL-5-B pulse generator450 V5 ns (2.5 ns opt)8-100ns2 kHzYES



We are here for you!




Drop us an email at info@simtrum.com to get the Best Price today.

Want more technical information? Click Here for the professional Customized System/ Solutions.




Don't have time to search the products one by one? No worries. you can download the full range of SIMTRUM Product Line Cards.

Click it now.


Want to stay closer to the Market Dynamics and Technological Developments? Just take 5 seconds to Sign In as a member of SIMTRUM, we will bring you the most up-to-date news.

(Sign in button on the top right of the screen).




Search Reset
Compare Model Drawings & Specs Max. PRF Rise Time (20%-80%) Output Voltage (Max) Availability Reference Price
(USD)
AVR-3HF-B pulse generator
general purpose, wide PW range, high PRF
100 kHz 2-3 Weeks Request for quote
AVRK-1-B pulse generator
fast rise time
1 kHz 2-3 Weeks Request for quote
AVR-8A-B pulse generator
general purpose, very wide PW range
1 kHz 2-3 Weeks Request for quote
AVRH-3-B pulse generator
high voltage, high impedance
1 kHz 2-3 Weeks Request for quote
AVR-E3A-B pulse generator
fast rise time, high PRF
200 kHz 2-3 Weeks Request for quote
AVRQ-4-B pulse generator
High Voltage, Wide PW range
4-6 Weeks Request for quote
AVRK-4-B pulse generator
General Purpose
4-6 Weeks Request for quote
AVOZ-E5-B pulse generator
General Purpose
4-6 Weeks Request for quote

AVOZ-E5-B pulse generator - Parameter

Max. PRF

Rise Time (20%-80%)

Output Voltage (Max)

AVRK-4-B pulse generator - Parameter

Max. PRF

Rise Time (20%-80%)

Output Voltage (Max)

AVRQ-4-B pulse generator - Parameter

Max. PRF

Rise Time (20%-80%)

Output Voltage (Max)

AVR-E3A-B pulse generator - Parameter

Max. PRF
200 kHz

Rise Time (20%-80%)

Output Voltage (Max)

AVRH-3-B pulse generator - Parameter

Max. PRF
1 kHz

Rise Time (20%-80%)

Output Voltage (Max)

AVR-8A-B pulse generator - Parameter

Max. PRF
1 kHz

Rise Time (20%-80%)

Output Voltage (Max)

AVRK-1-B pulse generator - Parameter

Max. PRF
1 kHz

Rise Time (20%-80%)

Output Voltage (Max)

AVR-3HF-B pulse generator - Parameter

Max. PRF
100 kHz

Rise Time (20%-80%)

Output Voltage (Max)
