单色仪&摄谱仪
| 型号 |
光谱范围 |
分辨率 |
准确度 |
重复性 |
焦深 |
F/# |
狭缝宽度 |
| 标准单光栅单色仪 |
330~1000 nm |
up to 0.5 nm |
up to 0.5 nm |
up to 0.25 nm |
100 mm |
F/3 |
300μm |
| 高分辨率单光栅单色仪 |
330~1000 nm |
up to 0.1 nm |
up to 0.2 nm |
up to 0.1 nm |
300 mm |
F/4.8 |
10μm~3mm |
| 双光栅扫描单色仪 |
200~2000 nm |
up to 0.2 nm |
up to 0.13 nm |
up to 0.05 nm |
150mm |
F/4.5 |
10μm~3mm |
| 三光栅扫描单色仪 |
200~2500 nm |
up to 0.05 nm |
up to 0.1 nm |
up to 0.05 nm |
300 mm |
F/4.8 |
10μm~3mm |
| 高分辨率三光栅扫描单色仪 |
200~2500 nm |
up to 0.03 nm |
up to 0.1 nm |
up to 0.05 nm |
500 mm |
F/8 |
10μm~3mm |
